Home » Skytron 3603 Ultraslide Surgical Table
Skytron

Skytron 3603 Ultraslide Surgical Table

SKU: EN-SKYTRON-3603
(0)
Condition
Category
LEAD TIME: Estimated Ship Time: 7-10 Days
PACKAGING: 1
WARRANTY: 3 Months
SHIPPING/RETURNS:
This product can be shipped to any location within the continental United States using FedEx Ground, UPS Ground, or Freight services. Shipping rates will be determined based on the destination zip code. For further information, please refer to our Shipping and Return policies.

Listing Terms & Conditions

All product and company names are trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement or sponsorship by them.

The Skytron 3603 ULTRASLIDE Surgical Table combines enhanced top slide functionality and power in a single table. With a robust design, it supports a lift capacity of 1,000 pounds and an articulation weight capacity of 800 pounds. The 3603 Ultra Slide Series stands out by providing an impressive 26 inches of top slide, surpassing competitors.

Notably, the table's articulation capacity is maintained during the slide function, a feature that sets it apart. As the tabletop moves toward the foot end, the head section can be easily detached and used as a foot extension. The table's versatility is further enhanced by removable back and leg sections, facilitating the quick attachment of accessories such as the 40″ carbon fiber extension and power beach chair.

Designed for convenience, the 3603 Ultra Slide Series offers pre-programmed positioning options, simplifying setup and enabling one-touch maneuvers at any point during the procedure. Confidence in the operating room is assured with the advanced features and capabilities of the Skytron 3603 ULTRASLIDE Surgical Table.

FEATURES:

  • PSR – Patient Safe Return Simultaneous return to level
  • Back lit back-up controls for emergency situations
  • New optional tunnel style x-ray tops
  • Self-leveling brakes for stability on uneven floors
  • 26” top slide
  • 10” slide to head and 16 ½” slide to foot
  • 1,000 lb lift and 800 lb articulation weight capacity
  • Removable back and leg sections for quick accessory attachment and positioning
  • Power beach chair positioner for one-touch set-up
  • Durable stainless steel base is easy to clean
  • Adjustable table height 3603 20 ½” to 39 ½” 3603H 23” to 41 ½”
  • 35° lateral tilt
  • 40° Trendelenburg and 30° reverse Trendelenburg

  • One-Touch Pendant Control
    • Simple one-touch operation
    • Backlit control for high visibility in low lighting
    • Audible alarm for kidney bridge, back up articulation and top slide obstruction
    • With PSR (Patient Safe Return)
    • Anatomically correct beach chair position
    • Recessed buttons prevent accidental activation
    • Durable and water resistant
    • Can be used in conjunction with optional three function foot control
SPECIFICATIONS:
  • Dimensions:
    • Length w/o head rest 69 1/2" 1765mm
    • Length with head rest 82" 2080mm
    • Width 20" 500mm
    • Width with side rails 22" 555mm

  • Adjustments via Pendant Control:
    • Height 3603 20 1/2" to 39 1/2" 520-1000mm 3603H 23" to 41 1/2" 580-1060mm
    • Lateral tilt (left/right) 35°
    • Trendelenburg 40°
    • Reverse Trendelenburg 30°
    • Power Kidney Bridge 6" 150mm Lift
    • Back up/down 90°/40°
    • Leg up/down 15/100°
    • Return to level (anatomically correct return to horizontal position from articulated positions)
    • Top slide/head 10" 250mm
    • Top slide/foot 16 1/2" 415mm
    • Flex/Reflex 40°/90°
    • Base braking (lock/unlock)
    • Beach Chair
    • Maximum permissible load 1,000lb (450kg) Lift 800lb (360kg) Articulation

  • Warranty: 90 Days
